Bi-Fold sliding

FOR FOLDIND & SLIDING DOORS

Advantages at a glance

Opening width of up to 6.3m
Ball-bearing raced roller gives smooth operation
Thermally broken threshold for low threshold design meeting DIN 18030
Schemes 220, 440 and 660 can be used with standard window profiles
Sash hinges with cleaning position

Unlimited options

With SIEGENIA-AUBI hardware there are no limits to the design possibilities for your folding sliding door. Top or bottom rail, inward or outward opening – it makes no difference. SIEGENIA-AUBI hardware systems give you unlimited choice.

A ball-bearing raced roller and folding hinges combination enables smooth and easy operation.

Painted hardware cover caps offer a wide range of colour options for your door.

Range of application

Sash width 330 to 900 mm
Sash rebate height 840 to 2360 mm
Sash weight max 80 kg

Outer frame width applies according to profile construction and sash width scheme

Easy access

Thanks to the new SIEGENIA-AUBI hardware you can now install folding sliding doors with a very low threshold. The thermal break prevents condensation build up. Built-in brushes ensure a dust and dirt-free running rail, which leads to longevity of use.

Light, air and space – exactly as you would like it

The new FS-PORTAL folding sliding door hardware from SIEGENIA-AUBI allows you to move the folding door to the side safely and easily, maximising the opening and allowing easy access to the outdoors. Using up to 7 sashes, you can create an opening of up to 6.3 meters.

Safe cleaning

Folding-sliding doors are ideal for balconied rooms, and thanks to the new SIEGENIA-AUBI FS-RS* sash hinge, the outside of the folding sash can be easily cleaned from the inside, whilst the sash stays in a secure position.
